1600mm High Speed Automatic Slitting Line for 0.3-3mm steel thickness metal plate

• Product Description

The 0.2-1.8 MM 1600MM Thin Sheet Slitting Line For Galvanized Steel Coil Materials consists of several components, including an decoiler to hold and feed the metal coil, a slitter head with multiple circular blades to cut the coil into strips, and a recoiler to wind the slit strips into individual coils. The line also incorporates tension control systems, edge guiding mechanisms, and scrap disposal units to ensure precise and efficient slitting operations.

• Why Choose This Slitting Line?

✅ Versatility: Processes HR, CR, and GI steels with varying strengths.
✅ Precision: ±0.1 mm width tolerance for ultra-narrow strips.
✅ High Speed: Up to 250 m/min for thin gauges.
✅ Low Labor: Optimized for minimal manpower.

Ideal for precision slitting of coils for automotive, construction, and appliance industries.

• Technical parameters

Note: Customized slitting line as per customer's requirements and demands would be available.

• Process flow:

From right to left are: Loading coil car→ Decoiler →Press and pinch device→Hydraulic cutter → Loop →Side guide device→ Double Slitter (with change car) → Scrap winder→ Loop → Tension stand →Recoielr→ Unloading coil car

• Applications

The 0.3-3.0 MM 1600MM Thin Sheet Slitting Linefinds its application in various industries that require precise and efficient processing of thin-gauge metal coils.

Automotive Industry: trim strips, brackets, reinforcements, and specialized parts

Electronics Industry: electronic components, including connectors, shielding materials, and stamped parts.

Construction Industry: roofing sheets, wall panels, and profiles.

Packaging Industry: packaging materials like aluminum foils, flexible packaging films, and paperboard laminates.

Appliances and Household Goods: household appliances and goods.

• Packaging & Shipping

Packaging:

All parts of the 0.3-3.0 MM 1600MM Thin Sheet Slitting Line are fixed inside container by steel wires and special PET straps, in order to make sure all parts will not move during transportation and avoid any kinds of damage of machine and container.

Shipping:

The 0.3-3.0 MM 1600MM Thin Sheet Slitting Line is often shipped via ocean freight, especially for international transportation. The equipment is securely loaded into shipping containers or flat racks, which are then loaded onto cargo vessels. This mode is suitable for long-distance shipping and can accommodate larger and heavier slitting lines.

Air Freight: When there is a need for fast delivery or for shipping smaller or lighter slitting line, air freight can be used. The equipment is packed and loaded onto aircraft for transportation. Air freight is typically more expensive than ocean freight but offers quicker transit times.

• FAQ

Q1. What is a Thin Sheet Slitting Line?
A Thin Sheet Slitting Line, also known as a slitting unit or slitting machine, is used to cut coil materials such as tinplate, galvanized iron, silicon steel sheet, cold rolled steel strip, stainless steel strip, aluminum strip, and steel strip into strips of various widths. These strips are then used in various industries such as transformers, motors, home appliances, automobiles, and packaging.

Q2. What materials can a Thin Sheet Slitting Line cut?

Thin Sheet Slitting Lines are capable of cutting various materials such as stainless steel, carbon steel, and galvanized steel coils.

Q3. What are the main types of Thin Sheet Slitting Lines?
Thin Sheet Slitting Lines can be categorized based on the thickness of the processed material and the type of metal material being slit. Based on thickness, there are thin plate slitting lines (0.1-3.0mm) and thick plate slitting lines (3.0-6.0mm). Based on the metal material, there are copper strip slitting lines, stainless steel slitting lines, cold plate slitting lines, silicon steel slitting lines, and tinplate slitting lines.

Q4. What are the advantages of using a Thin Sheet Slitting Line?
Thin Sheet Slitting Lines offer several advantages, including:

• Convenient operation
• High cutting quality
• High material utilization

Q5.  How much does a Thin Sheet Slitting Line cost?
The price of a Thin Sheet Slitting Line depends on factors such as the specifications of the steel coil and the degree of automation of the equipment.
